Carlingford tilastot

Here you can find statistics of the TOA lightning detection station Carlingford.

  • ID: 2093
  • Firmware: 8.4b1
  • Controller: 19.4
  • Amplifier: H1 / E1
  • Antenni 1+2: Ferrite rod, length=200mm
  • Website: carlingfordweather.sydney
  • Comment: H-Field External 2x200mm Ferrites

General statistics of the last hour

  • Asema aktiivinen: yes
  • Last update: noin 3,195,992.1 minuuttia sitten
  • Viimeisin havaittu salamanisku: None
  • Salamaniskut: 171
  • Signaalit: 576
  • Paikannussuhde: 29.7%
  • Iskusuhde: 9.9%
  • Strokes station min participants (13-18 Asemat): 7 (0.4%)

GPS

Some information about the GPS receiver, which is used for receiving the exact time an position. If known, the antenna bearings are also displayed (red, green).

  • Viimeisin sijainti: -33.771706° / 151.036865°
  • Last time without GPS: 2018-10-24 02:00:27

Salamaniskujen tiheys

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Carlingford and the mean stroke count for all stations

Graafit: Salamastatistiikka

Signaalien tiheys

The count of received signals per hour of the station Carlingford and also mean value of all stations.

Graafit: Signaalistatistiikka

Suhteet

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Graafit: Paikannus- ja iskusuhteet

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Graafit: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Graafit: Salamaniskujen suhde suuntaan
