Statistics

Statistics of station Carlingford

Here you can find statistics of the TOA lightning detection station Carlingford.

  • Id: 2093
  • Firmware: 8.4b1
  • Controller: 19.4
  • Amplifier: H1 / E1
  • Antenna 1+2: Ferrite rod, length=200mm
  • Website: carlingfordweather.sydney
  • Comment: H-Field External 2x200mm Ferrites

General statistics of the last hour

  • Station active: igen
  • Last update: 3.200.478,9 minutes ago
  • Last detected stroke: None
  • Strokes: 171
  • Jelek: 576
  • Locating ratio: 29,7%
  • Stroke ratio: 9,9%
  • Strokes station min participants (13-18 stations): 7 (0,4%)

GPS

Some information about the GPS receiver, which is used for receiving the exact time an position. If known, the antenna bearings are also displayed (red, green).

  • Last position: -33,771706° / 151,036865°
  • Last time without GPS: 2018.10.24 02:00:27

Stroke count

Here you can see the whole stroke count per hours detected by the lightning network, the count of detected strokes/h of the station Carlingford and the mean stroke count for all stations

Grafikonok: Stroke statistics

Signal count

The count of received signals per hour of the station Carlingford and also mean value of all stations.

Grafikonok: Signal statistics

Ratios

Stroke and locating ratios are important parameters for the correct adjustment of the station. Calculations:
locating ratio = (detected strokes of the station) / (signals of the station)
stroke ratio = (detected strokes of the station) / (network stroke count)

Grafikonok: Locating and stroke ratios

Stroke ratio by distance

Overview about the own locating ratio over distance from stations. Whole stroke count over distance is also visible.

Grafikonok: Stroke ratio by distance

Stroke ratio by bearing

Own locating ratio over the geographic direction. For better comparision, there is also the whole stroke count visible.

Grafikonok: Stroke ratio by bearing
